= Additional options and accessories =

- Ad blue

= Remarks =

Hopper Capacity: 7 cu/yd

Basic Body Dimension

Body (LxWxH): 260” x 102”’ x 108”
Loading Height: 74”
Net Weight: 18,600 lbs (8437 kg)
Conveyor Placement System:

32” apron chain centers, 26” wide live-bottom unloading system
19’ throw conveyor c/w W.K. Dahms ½” high cleat belt
Drive system

CAT C4.4TA (Tier 4F) 131 HP, fuel efficient self-contained diesel power with direct coupled hydraulic pumps
Engine and system control via Hetronic / Sauer Danfoss CANBUS
Danfoss closed loop piston pumps and motors on drive system
Danfoss variable displacement pumps and load sense valves on Stone Slinger functions
Planetary gearbox with direct coupled hydraulic motor on swing frame for conveyor rotation
4 steering modes controlled via transmitter ~ front, rear, articulated & crab
Standard Features:

Super-Shield™ Power Drive matches conveyor speed for improved control
Double pivot swing frame with 250° degree working pivot radius
Low overall profile to access indoor work sites
Hopper wing extensions reduce material spillage and waste; feed with larger loaders and excavators

= More information =

General information
Field of application: Construction

Drivetrain
AdBlue system: Yes
Make of engine: C4.4

Condition
General condition: very good
Technical condition: very good
Visual appearance: very good

Other information
EPA Marked: yes
Emission level: Stage V / Tier IV final
Delivery terms: EXW
Transport dimensions (LxWxH): 6,6x2,59x2,75
Production country: CA

Additional information
Please contact Bart Apers, Jeroen Heindryckx or Matthias Eyckmans for more information

- Система AdBlue

- Systém AdBlue

= Weitere Optionen und Zubehör =

- AdBlue

= Weitere Informationen =

Allgemeine Informationen
Verwendungszweck: Bauwesen

Antriebsstrang
AdBlue-System: Ja
Motormarke: C4.4

Zustand
Allgemeiner Zustand: sehr gut
Technischer Zustand: sehr gut
Optischer Zustand: sehr gut

Weitere Informationen
Emissionsniveau: Stage V / Tier IV final
Lieferbedingungen: EXW
Transportabmessungen (L x B x H): 6,6x2,59x2,75
Produktionsland: CA

Weitere Informationen
Wenden Sie sich an Bart Apers, Jeroen Heindryckx oder Matthias Eyckmans, um weitere Informationen zu erhalten.

= Flere valgmuligheder og mere tilbehør =

- AdBlue-system

= Yderligere oplysninger =

AdBlue-system: Ja
Anvendelsesområde: Konstruktion
Motorfabrikat: C4.4
Overordnet stand: meget god
Teknisk stand: meget god
Visuelt udseende: meget god
Kontakt Bart Apers, Jeroen Heindryckx eller Matthias Eyckmans for yderligere oplysninger

- Σύστημα AdBlue

= Más opciones y accesorios =

- Sistema AdBlue

= Más información =

Información general
Ámbito de aplicación: Construcción

Cadena cinemática
Sistema de AdBlue: Sí
Marca motor: C4.4

Estado
Estado general: muy bueno
Estado técnico: muy bueno
Estado óptico: muy bueno

Información adicional
Nivel de emisión: Stage V / Tier IV final
Terminos de entrega: EXW
Dimensiones de transporte (LaxAnxAl): 6,6x2,59x2,75
País de producción: CA

Información complementaria
Póngase en contacto con Bart Apers, Jeroen Heindryckx o Matthias Eyckmans para obtener más información.

- AdBlue-järjestelmä

= Plus d'options et d'accessoires =

- Système AdBlue

= Plus d'informations =

Informations générales
Domaine d'application: Construction

Transmission
Système AdBlue: Oui
Marque moteur: C4.4

Condition
État général: très bon
État technique: très bon
État optique: très bon

Autres informations
Niveau d'émission: Stage V / Tier IV final
Conditions de livraison: EXW
Dimensions du volume de transport (L x l x H): 6,6x2,59x2,75
Pays de production: CA

Informations complémentaires
Veuillez contacter Bart Apers, Jeroen Heindryckx ou Matthias Eyckmans pour plus d'informations

- Sustav AdBlue

- AdBlue rendszer

= Aanvullende opties en accessoires =

- AdBlue

= Bijzonderheden =

Hopper Capacity: 7 cu/yd

Basic Body Dimension

Body (LxWxH): 260” x 102”’ x 108”
Loading Height: 74”
Net Weight: 18,600 lbs (8437 kg)
Conveyor Placement System:

32” apron chain centers, 26” wide live-bottom unloading system
19’ throw conveyor c/w W.K. Dahms ½” high cleat belt
Drive system

CAT C4.4TA (Tier 4F) 131 HP, fuel efficient self-contained diesel power with direct coupled hydraulic pumps
Engine and system control via Hetronic / Sauer Danfoss CANBUS
Danfoss closed loop piston pumps and motors on drive system
Danfoss variable displacement pumps and load sense valves on Stone Slinger functions
Planetary gearbox with direct coupled hydraulic motor on swing frame for conveyor rotation
4 steering modes controlled via transmitter ~ front, rear, articulated & crab
Standard Features:

Super-Shield™ Power Drive matches conveyor speed for improved control
Double pivot swing frame with 250° degree working pivot radius
Low overall profile to access indoor work sites
Hopper wing extensions reduce material spillage and waste; feed with larger loaders and excavators

= Meer informatie =

Algemene informatie
Toepassingsgebied: Bouw

Aandrijving
AdBlue-systeem: Ja
Merk motor: C4.4

Staat
Algemene staat: zeer goed
Technische staat: zeer goed
Optische staat: zeer goed

Overige informatie
Emissieklasse: Stage V / Tier IV final
Leveringsvoorwaarden: EXW
Afmetingen (LxBxH) (m): 6,6x2,59x2,75
Productieland: CA

Meer informatie
Neem voor meer informatie contact op met Bart Apers, Jeroen Heindryckx of Matthias Eyckmans

- AdBlue-system

= Więcej opcji i akcesoriów =

- Układ płynu AdBlue

= Więcej informacji =

Układ AdBlue: Tak
Obszar zastosowania: Budownictwo
Marka silnika: C4.4
Stan ogólny: bardzo dobrze
Stan techniczny: bardzo dobrze
Stan wizualny: bardzo dobrze
Aby uzyskać więcej informacji, należy skontaktować się z Bart Apers, Jeroen Heindryckx lub Matthias Eyckmans

= Opções e acessórios adicionais =

- Sistema de AdBlue

= Mais informações =

Sistema de AdBlue: Sim
Campo de aplicação: Construção
Marca do motor: C4.4
Estado geral: muito bom
Estado técnico: muito bom
Aspeto visual: muito bom
Contacte Bart Apers, Jeroen Heindryckx ou Matthias Eyckmans para obter mais informações

- Sistem AdBlue

= Дополнительные опции и оборудование =

- Система AdBlue

= Дополнительная информация =

Система AdBlue: Да
Область применения: Строительство
Марка двигателя: C4.4
Общее состояние: очень хорошее
Техническое состояние: очень хорошее
Внешнее состояние: очень хорошее
Свяжитесь с Bart Apers, Jeroen Heindryckx или Matthias Eyckmans для получения дополнительной информации

- Systém AdBlue

= Extra tillval och tillbehör =

- AdBlue-system

= Ytterligare information =

AdBlue-system: Ja
Omfattning: Konstruktion
Motormärke: C4.4
Allmänt tillstånd: mycket bra
Tekniskt tillstånd: mycket bra
Optiskt tillstånd: mycket bra
Kontakta Bart Apers, Jeroen Heindryckx eller Matthias Eyckmans för mer information

- AdBlue sistemi
